VIPRAM PLY / DOOR COLLECTION
FLUSH DOORS
Explore VIPRAM Flush Doors for residential and commercial spaces, with smooth finishing options and thickness choices to suit different requirements.
Product overview
Flush doors for
everyday spaces.
Finish, choice and use
VIPRAM Flush Doors are presented for customers looking for a clean, smooth door finish for residential and commercial interiors. The supplied product description highlights durable construction, a neat appearance and options that can be discussed according to project requirements.
Veneer and laminate finishes are mentioned in the supplied material. A smooth, low-groove surface can be easier to wipe clean with a dry cloth as part of routine care.
Construction and customization
The supplied description refers to a timber frame covered with quality plywood or MDF, and describes solid-core or laminated flush-door options. It also mentions cross-band veneers, resin bonding, quality control and filling hollow side spaces with cardboard in the construction described by the source.
Confirm the exact construction, finish and configuration of the specific door model before ordering, as these details can vary by product.
ResidentialCommercialInterior DoorsVeneer FinishLaminate FinishCustomized Options
Available options
Door thicknesses.
The supplied description lists these thicknesses and notes that customized thickness may be requested. Confirm current availability before ordering.
30mm thickness
32mm thickness
35mm thickness
Custom thickness: The supplied source mentions customized thickness options. Specific sizes and availability should be confirmed with the Vipram Ply team.
Technical information
Technical specifications (IS:2202)
The table below transcribes the test names, requirements and observed values from the technical specification image provided.
| S. No. | Test | ISI Requirement | Observed Value |
|---|---|---|---|
| 1 | Dimension | Length, width: ±5 mm; thickness: ±1 mm | Within limits |
| 2 | Squareness | Deviation not more than 1 mm on a length of 500 mm | Deviation below 1 mm |
| 3 | General Flatness | Twist, cupping, warping not to exceed 6 mm | — |
| 4 | Local Planeness | Depth of deviation at any point to be less than 0.5 mm | Within limits |
| 5 | Impact Indentation Test | Depth of indentation not to exceed 0.2 mm | Within limits |
| 6 | Edge Loading Test | Deflection of edge with max. to be less than 5 mm | Within limits |
| 7 | Shock Resistance Test | No visible defect after test | No visible defects |
| 8 | Buckling Test | Initial deflection < 50 mm; residual deflection < 5 mm | Within limits |
| 9 | Slamming Test | No visible damage after test | No visible damage |
| 10 | Misuse Test | No deformation after test | No deformation |
| 11 | Varying Humidity Test | No visible warping, twisting or delamination | No such defects observed |
| 12 | End Immersion Test | No delamination at the end | No delamination |
| 13 | Knife Test | Minimum pass standard | Excellent |
| 14 | Glue Adhesion Test | No delamination | No delamination |
| 15 | Screw Withdraw Test | Load to withdraw screw to be more than 1000 N | Load > 1000 N |
VIPRAM FLUSH DOORS
KEY FEATURES
Features described in the supplied Flush Door product material.
Suitable for residential and commercial use
Security and privacy
Customized solutions for different requirements
Lock configurations on both sides can be designed
Door collection
WHY VIPRAM PLY
Door options and finishing can be discussed according to the requirements of your space.
